1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

Shenzhen Herolaser Equipment Co., Ltd.
Contact Now

1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

Brand Name : Herolaser

Model Number : ML-WF-BP-IW1000

Certification : ISO9001, CE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 20 sets per month

Delivery Time : 7 work days

Packaging Details : Wooden case

Condition : New

Wavelength : 1070nm

Dimension : 1050*670mm*1200mm

Welding Thickness : 0.5-3mm

Certificates : CE, ISO

Laser Source : IPG / MAX

Weight : 230KG

Welding Gap : <0.5mm

Warranty of core components : 2 Years

Contact Now

1500w Herolaser Hand-held Laser Welder Welding Machine for Iron Steel Metal4
Parameter
Items
Parameter
Equipment Name
Handheld fiber laser welding machine
Laser Power
500W,800W,1000W,2000W,3000W
Laser Wavelength
1070 NM
Fiber Length
Standard 10M Maximum 15M
Work Way
Continuously modulated
Water Chiller
Industrial thermostatic water tank
Working Environment Temperature
15~35 ℃
Working Environment Humidity
-17%without condensation
Suggested Welding Thickness
0.5-5mm (depends on the materials)
Welding gap requirement
≤0.5mm
Working Voltage
220V/380V 50Hz
Dimension
1050mm x 670mm x 1200mm
Total Weight
240kg
Welding penetration data (wobble welding head)
Power
Stainless Steel
Carbon Steel
galvanized plate
500W
0.5-0.8mm
0.5-0.8mm
0.5-0.8mm
800W
0.5-1.2mm
0.5-1.2mm
0.5-1.0mm
1000W
0.5-1.5mm
0.5-1.5mm
0.5-1.2mm
2000W
0.5-3mm
0.5-3mm
0.5-2.5mm
Products Description
Water-cooled handheld laser welding machine

Most sales in the market are dominated by water-cooled hand-held welding. Water-cooled hand-held welding uses water

as thecooling medium. Our company sells water-cooled welding machines with different powers such as 500W, 800W,

1000W, 1500W, 2000W, 3000W, etc. And hand-held welding focuses on three models: 1000W, 1500W, and 2000W.

Water-cooled handheld welding machine features: built-in dual-temperature dual-control industrial chiller, constant temperature

regulation and heat dissipation, to ensure the heat dissipation of the core optical circuit components. With fiber laser, stable
and efficient
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
Characteristics
Features of Handheld Laser Welding Machine

Advantages of handheld laser welding machine

Simple operation, can be easily operated with simple training; beautiful products can be welded one take without a master
WOBBLE handheld laser head, light and flexible, can weld any part of the workpiece, making the welding work more
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
Process characteristics of hand-held laser welding machine
The welding seam is smooth and beautiful, the welding workpiece has no deformation, no welding scar, the welding is firm, and the
subsequent grinding process is reduced, saving time and cost.
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

Advantages of handheld laser welding machine
Simple operation, can be easily operated with simple training; beautiful products can be welded one take without a master
WOBBLE handheld laser head, light and flexible, can weld any part of the workpiece, making the welding work more efficient,
safe,energy-saving and environmentally friendly.
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

Related Laser Machine
Herolaser special in laser industry for about 17 years.In addition to handheld laser welding machine, we also have automatic
welder with robot arm, laser cleaning machines, laser deep engraving machine and laser marking machine.
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
Applicable Industry
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
AIRSHIP AUTO PARTS
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

MEDICAL EQUIPMENT
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

METAL PROCESSING
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

MACHINE MANUFACTURING
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

ELEVATOR MANUFACTURING
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper

HOUSEHOLD APPLIANCES
Company Information
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
ABOUT HEROLASER
Shenzhen Herolaser Equipment Co., Ltd was established in 2004, is a national high-tech enterprise in China, engaged in the
research and development, production and marketing of laser equipment group of companies, has formed a complete series of
industrial laser equipment supply platform.

With a team of professional technical personnel,rich management experience, clear development direction to ensure our rapid growth
in the rapid development of the laser industry,we have established branches in Jiangsu, Zhejiang,Shandong, Chongqing and other
regions in China, and we have exported to 60 countries and have overseas agents in 10 countries. Our main products is Laser
Cleaning Machine / Laser Marking Machine / Laser Welding Machine / Laser Cutting Machine.

Products are widely used in electrical appliances, mobile communications, hardware products, tool accessories, precision
equipment, jewelry, glasses and watches, integrated circuits, craft gifts, plastic molds, medical equipment and other industries.
Certification
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
Packaging & Shipment
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
1070nm IPG / MAX Fiber Laser Welding Machine For Metal Aluminum Copper
Our Services

---Pre-Sales Service
① Free pre-sales 7*24 hours rapid response services / cousulting ② Free sample testing / inspection ③ Free design of fixtures as customers / distributor required ④ Strict quality control for our products ⑤ Quick delivery time
---After-sales Services
① 2 year guarantee for laser source(people damaged are charged) ② Full technical support / by e-mail, call and video ③ Spare parts supply. ④ Free online training installation and operation ⑤ 12 hours quick feedback & after-sales services ⑥ ODM/OEM service
FAQ
1. What model does Herolaser produce?

Production of Laser Welding series, Laser Cleaning series, Laser Cutting series and Laser New energy automation, etc.

2. What are the payment methods of Herolaser Company?

T/T, LC, CAD, OA, Trade Insurance, Alibabapay

3. Does Herolaser accept Acceptance?

Yes, we accept bank acceptances within 6 months, not commercial acceptances.

4. Can I visit the factory?

Available to have a visit to our factory at any time.

5. What can I get with the purchase of equipment?

Each machine has a set of standard accessories.

6. Can I go to the factory to test the machine before shipment?

Of course you can.

7.How is the delivery and shipment?

Ship in 7 days after 100% payment; Packaged with Plywood box.

8. How about your pre-sales service?

Provide quick response and free consulting services within 8 hours.
