Handheld 1000W 1500W 2000W Laser Welding Machine For Mold Repairing

Name: Handheld 1000W 1500W 2000W Laser Welding Machine For Mold Repairing
Brand: HEROLASER
Price: 1 USD

Wholesale Handheld 1000W 1500W 2000W Laser Welding Machine For Mold Repairing from china suppliers

Brand Name : HEROLASER

Model Number : ML-1000

Certification : CE,ISO,SGS

Place of Origin : CHINA

MOQ : 1 Set

Price : Negotiable

Payment Terms : Western Union, L/C, T/T, MoneyGram

Supply Ability : 200 Sets per Month

Delivery Time : 10-15 days

Packaging Details : Export Plywood Box

Laser Source : IPG, MAX, Raycus, RECI

Key Words : Portable Handheld Laser Welder, Flexible Handheld Laser Welding, Fiber Laser Mold Welding, Flexible Mold Laser Repairing

Pulse width : 0.5~20ms

Condition : New

Warranty : 2 Years

Single pulse energy : 80J

Wavelength : 1064nm

Focal spot diameter : 0.2-3.0mm

Application : Laser Welding Machine,Welding Products,hot selling laser welding machine for Metal Stainless Steel repairing,advertisement word and all kinds of metal marking LED metal,Mold repair laser welding

Cooling system : Water Cooling

Welding depth : 0.1-3.5mm

After-sales service provided : Engineers available to service machinery overseas,Overseas third-party support available

Pulse frequency : 0.1-50Hz

Laser wavelength : 1064nm

Power supply : 220v/50Hz,50/60Hz,380V/50/60HZ

Laser type : IPG fiber laser generator

Contact Now

Flexible Handheld Laser Welder For Mold Repairing Fiber Laser Welding Machine 1000W 1500W 2000W

Machine Advantages
1. The welding seam is smooth and beautiful, which reduces the subsequent grinding process and saves time and cost.

2. Easy to operate, no need welding work license, unskilled operator can also weld products beautifully.

3. No effect for etch after welding , low oxidation rate ,the color of the processing parts is intact .

4. The welding seam is smooth and beautiful, which reduces the subsequent grinding process and saves time and cost.

5. The welding speed is 2-10 times faster than the traditional welding speed. It can help you to save at least two welding operators a year.

6. Laser welding consumes less material and has a long-life, Safer and more environmentally friendly.

Applicable to material and fields
Ambry industry, railings of stairs and elevator , shelves, oven, stainless steel guardrail , distribution box, stainless steel home supplies etc.

Technical specifications

No.	Item	ML-WF-1000W	ML-WF-1500W	ML-WF-2000W
1	Laser Power	1000W	1500W	2000W
2	laser Wavelength	1070 NM	1070 NM	1070 NM
3	Fiber Cable length	10 meters	10 meters	10 meters
4	Cooling method	Water	Water	Water
5	Voltage	220V	220V	380V
6	Power consumption	5KW	7KW	9KW
7	Frequency	50/60 HZ	50/60 HZ	50/60 HZ
8	Currency	23A	32A	23A
9	Laser gun	Motor/lens wobble	Motor/lens wobble	Motor/lens wobble
10	Focus length	150mm	150mm	150mm
11	Cryogenic water flow	70 L/min	70 L/min	83 L/min
12	Room temperature water flow	15 L/min	18 L/min	18 L/min
13	water	distilled water
14	laser Control method	laser enable+ security lock+ metal switch/ safety clamp
15	Touch screen	PLC screen and board
16	Wire feeder	auto feeding and drawback

Welding data:

Material	Protective gas	Welding depth	500W	1000W	1500W	2000W
Aluminum	N2	1.0		√	√	√
		1.2		√	√	√
		1.5			√	√
		2.0			√	√
		2.5				√
Stainless Steel	Argon	0.5	√	√	√	√
		0.8	√	√	√	√
		1.0	√	√	√	√
		1.2		√	√	√
		1.5		√	√	√
		2.0		√	√	√
		2.5			√	√
		3.0				√
Carbon steel	CO2	0.5	√	√	√	√
		0.8	√	√	√	√
		1.0	√	√	√	√
		1.2		√	√	√
		1.5			√	√
		2.0			√	√
		2.5			√	√
galvanized sheet	Argon	0.5	√	√	√	√
		0.8	√	√	√	√
		1.0		√	√	√
		1.2		√	√	√
		1.5			√	√
		2.0				√
		2.5				√

Remark: welding depth is not equal to material thickness, which of 6mm can be weld by 2000W model.
