Herolaser Automated CNC Optical Fiber Laser Welding Machine For Stainless Steel

Name: Herolaser Automated CNC Optical Fiber Laser Welding Machine For Stainless Steel
Brand: Herolaser
Price: 1 USD

Wholesale Herolaser Automated CNC Optical Fiber Laser Welding Machine For Stainless Steel from china suppliers

Brand Name : Herolaser

Model Number : ML-WF-ZD-4D-HW6000

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 20 sets per month

Delivery Time : 30-45 days

Packaging Details : Wooden case

Dimensions : 1600×1400mm×1900mm

Machine weight : 680kg

electricity demand : 220V/380V

Average load power : 16.6KW

X axis effective stroke : 500mm

Y/Z axis effective stroke : 300mm

Contact Now

Four-axis Auto Soldering Welding Machine Automatic Laser Welders

Parameter

Main technical parameters of the equipment
Product Specifications
S/N	Main component name	Parameter	Remark
1	X axis effective stroke	500mm
2	Y axis effective stroke	300mm
3	Z axis effective stroke	300mm
4	Dimensions	1500×1400×1900mm
5	Machine weight	680kg
6	Module operating speed	Y axis:10m/min X axis:10m/min Z axis:5m/min
7	repeated positioning accuracy	±0.02mm
8	Rotating table	Circle runout accuracy ≤0.05mm
9	electricity demand	220V/380V
10	Average load power	16.6KW

Equipment configuration list
Configuration Parameter
S/N	Name	Specifications & Models	QTY	Brand	Remark
1	Fixture mounting plate	350mm×450mm	1	Hero Laser Custom
2	Laser	According to sample welding requirements	1	MAX or IPG
3	Motor	servo motor	3	Huichuan
4	Computer	PC/Industrial Computer	1	Advantech
5	Chiller	According to laser power	1	S & A
6	Welding head	According to sample welding requirements	1	Hero Laser
7	CCD Visual observation system	camera light source	1	Microsan Basler/LeTV Light Source
8	Z axis module	300mm stroke	1	Hero Laser Custom	X, Y axis screw lead 10mm, Z axis screw lead 5mm; screw accuracy: C7
9	X axis module	500mm stroke	1	Hero Laser Custom
10	Y axis module	300mm stroke	1	Hero Laser Custom
11	Rotating table	Three-jaw rotary chuck	1	Hero Laser Custom
12	Lower cabinet	Sheet metal welding, paint baking	1	Hero Laser Custom

Herolaser Automated CNC Optical Fiber Laser Welding Machine For Stainless Steel

Products Description

Six-dimensional automatic welding machine

Herolaser automatic laser welding machine adopts manual design, simple and convenient installation and operation, adopts self-equipped cooling system, does not need any external water tower for water cooling, the maximum frequency can reach 100HZ, the linear speed can reach 8mm/s, which greatly improves the welding efficiency and welding quality. It can also be equipped with a four-dimensional ball screw table, using an imported servo control system, including a rotating table, which can weld cylindrical objects and other objects of various shapes, with a wide range of applications, high precision and fast speed.

The current waveform can be adjusted arbitrarily, which can be applied to various materials and alloys.

Herolaser Automated CNC Optical Fiber Laser Welding Machine For Stainless Steel

1. Cost saving: achieved by improving speed, weakening the requirements of manual skills and reducing post welding processes:

a. The speed is 3-10 times of that of traditional welding, and one machine can save 3-5 welders;

b. It takes half a day to complete from learning to proficiency, without relying on manual skills;

c. System control, smooth and even welding seam, reduce grinding and polishing process.

2. Environmental protection: Welding dust splashes and produces harmful gas during the operation of traditional welding machines, which is harmful to the environment and workers' health, while the laser welding machine with laser inscription has almost zero environmental hazard.

3. Less consumables, long service life: 17 years of experience in laser equipment production and R&D, stable technology, and life-long after-sales guarantee for the machine.

4. Strong expansibility: manipulator or CNC welding machine can be expanded and configured, and ordinary handheld head or swinging handheld head can be replaced to meet various welding requirements;

5. Small influence on the hot area: the laser welding hot area is concentrated, the workpiece is free of deformation and welding scar, and the welding is firm.

6. Full set of professional welding nozzles: meet the welding process requirements of butt welding, fillet welding, overlap welding


Sample Show

Applicable Industry

mobile phone batteries

jewelry

electronic components

precision machinery

communications

handicrafts

Installation Instructions

ABOUT HEROLASER

Shenzhen Herolaser Equipment Co., Ltd was established in 2004, is a national high-tech enterprise in China, engaged in the
 research and development, production and marketing of laser equipment group of companies, has formed a complete series of
 industrial laser equipment supply platform.

 With a team of professional technical personnel,rich management experience, clear development direction to ensure our rapid growth
 in the rapid development of the laser industry,we have established branches in Jiangsu, Zhejiang,Shandong, Chongqing and other
 regions in China, and we have exported to 60 countries and have overseas agents in 10 countries. Our main products is Laser
 Cleaning Machine / Laser Marking Machine / Laser Welding Machine / Laser Cutting Machine.

 Products are widely used in electrical appliances, mobile communications, hardware products, tool accessories, precision
 equipment, jewelry, glasses and watches, integrated circuits, craft gifts, plastic molds, medical equipment and other industries.

Certification

Packaging & Shipment

Our Services

---Pre-Sales Services

① Free pre-sales 7*24 hours rapid response services / cousulting ② Free sample testing / inspection ③ Free design of fixtures as customers / distributor required ④ Strict quality control for our products ⑤ Quick delivery time

---After-Sales Services
① 2 year guarantee for laser source(people damaged are charged) ② Full technical support / by e-mail, call and video ③ Spare parts supply. ④ Free online training installation and operation ⑤ 12 hours quick feedback & after-sales services ⑥ ODM/OEM service


FAQ

1. What model does Herolaser produce?
 Production of Laser Welding series, Laser Cleaning series, Laser Cutting series and Laser New energy automation, etc.

 2. What are the payment methods of Herolaser Company?
 T/T, LC, CAD, OA, Trade Insurance, Alibabapay

 3. Does Herolaser accept Acceptance?
 Yes, we accept bank acceptances within 6 months, not commercial acceptances.

 4. Can I visit the factory?
 Available to have a visit to our factory at any time.

 5. What can I get with the purchase of equipment?
 Each machine has a set of standard accessories.

 6. Can I go to the factory to test the machine before shipment?
 Of course you can.

 7. How is the delivery and shipment?
 Ship in 7 days after 100% payment; Packaged with Plywood box.

 8. How about your pre-sales service?
 Provide quick response and free consulting services within 8 hours.

 9. How will you guarantee after-sales services?
 We offer two years warranty for laser source, one year for the machine.

 10. How will you guarantee after-sales services?
 We offer two years warranty for laser source, one year for the machine.
