Small Integrated Design CO2 Laser Marking Machine with Advanced Galvanometer Marking
Product introdution:
CO2 radio frequency laser is a gas laser with a laser wavelength of 10.64nm, which belongs to the mid-infrared band. CO2 laser has high power and photoelectric conversion rate. Carbon dioxide laser takes carbon dioxide as the working material and fills the discharge tube with auxiliary gases such as carbon dioxide. When a high voltage is applied to the electrode, a glow discharge occurs in the discharge tube, which causes the gas molecules to release the laser. After the laser beam is expanded and focused, it is processed by a deflection scanning mirror.
Characteristics and features:
-Perfect for harsh environments
-Sturdy metal laser tube (above 20000 hours life) Easily replaceable metal laser tube
-Aluminum alloy lifting work table
-Compact and low maintenance
-Easy operation
-Supports a variety of file formats
(JPG, JPEG, TIF, PLT, DXF, DST, BMP, PNA and others)
-Efficient water cooling system
-The high-speed flow pump offers working stability
-Amazing versatility
-High-precision marking up to 2 mm deep
-Software supports all characters, numbers, codes & graphics
Technical details:
| Model | ML-MC-KF-00-HW70 |
| Wave Length(um) | 9.3/10.2/10.6 |
| Output Power(W) | ≥70 |
| Marking Speed | ≥7m/s |
| Marking Area | 110mm |
| Marking Focus | 150mm |
| Marking Font | Scribing, dot matrix |
| Marking Mode | Static and dynamic |
| Online Speed | ≤120m/min |
| Marking Material | Label, paper, PET, HDPE, glass, wood, etc |
| Temperature | 5-35℃ |
| Humidity | Relative humidity<95%, frost-free |
| Structure Material | High-quality aluminum alloy; stainless steel |
| Edit Mode | Computer software |
| Communication Interface | USB Interface |
| Power Supply | AV220V/50,60HZ |
| Rated Power | 1200W |
Application:
Widely used in clothing accessories, leather, food and beverage packaging, electronic components, arts and crafts, glass stone processing and other fields of graphic marking and cutting. It can also be used for marking many non-metallic materials, such as paper packaging, plastic products, labels, leather fabrics, glass ceramics, resin plastics, wood products, PCB board and so on.
Marking samples for reference:
FAQ
1. How is the payment?
- 30% deposit before production and the balance 70% before shipment
2. How is the delivery and shipment?
- Ship in 7 days after 100% payment;
- Plywood box packaging
3. How will you guarantee aftersales services?
- We offer two warranty for laser source, one year for whole machine and lifetime maintenance services.
- Engineers available to service machinery overseas
- Free technical training in our factory
- Free sample can be sent to you
- Professional technical team 24 hours online
4. How about your presales service?
- Speeding offer within 8 hours quick response and free consulting.
- Free sample marking or testing is available
- Progressing solution design to all clients, including distributors and end users.
